**Bundles for vibrant and colourful content visualisation **
Displaying deep blacks and extreme contrast levels, content appears remarkably vivid for an immersive and engaging viewer experience even under demanding ambient conditions.
The direct VIew LED-FC series bundles use the latest flip-chip CoB technology to deliver stunning image performance with a state-of-the-art level of quality while increasing energy efficiency significantly to ensure reduced operating cost during its entire lifetime.
The durability, high contrast ratio, and brightness of the FC series make it a great fit for a wide range of demanding applications in transportation, museums, meeting space and many more.
- Excellent contrast ratio of up to 20000:1 and deep black level – ensures content is presented in vivid clarity for the best possible viewing experience.
- Significantly lowering your energy usage – CoB technology is highly efficient, consuming up to 40% less power compared to standard SMD technology at the same brightness output.
- Established mechanical cabinet design – supports wall mounted or freestanding installation with speed and ease, achieving precision module alignment for a single large surface perception.
- Excellent visual performance – unseen colour reproduction with excellent off angle performance.
- Secure investment in high-end dvLED visualisations – CoB technology enables installations to be more robust and long lasting.
Special Characteristics
Single Data Receiving Cards; Single Power Supplies
Skærm
- Billed diagonal
- 165 "
- Skærmopløsning
- 3840x2160
- Pixel pitch
- 0,9 mm
- Diode Type
- COB (0408)
- Opdateringshastighed
- 3.840 Hz
- Brightness (Max)
- 800 Nits
- Viewing angle
- 160 ° Horizontal / 150 Vertical
LED Modul/kabinet
- No. cabinets/display (WxH)
- 6x6
- No. modules/cabinet (WxH)
- 6x6
- Cabinet Resolution
- 640 x 360
- Modul opløsning
- 4x2
Tilslutninger
- Video ind
- HDMI x1
- Ethernet
- Ja x1
Energi
- Consumption Max/m2
- 289 W
- Consumption Max tot.
- 2.160 W
Dimensioner og vægt
- Bredde
- 3.688 mm
- Højde
- 2.176,5 mm
- Dybde
- 82 mm
- Nettovægt
- 325 kg
Yderligere oplysninger
- Service access
- Front Service
- IP Classification
- IP20; IP40
- Min driftstemperatur
- -20 Celsius
- Max driftstemperatur
- 40 Celsius
- Inkluderet tilbehør
- 1x LED Controller; LED Modules (36 Cabinets, 288 Pixel Cards); Overframe Kit (6x6); Pixel Card Removal Tool; Power Bar; Spare Parts Kit; Wall mount (6x6)
- Garanti
- 3 år
Forpakningsinfo
- Forpaknings størrelse
- 1.800 x 800 x 1.400 mm
- Forpaknings vægt
- 266,00 kg
