The first AOPEN Intel-based system capable of supporting hardware accelerated AV1 8K playback. As if that wasn’t enough, the DEX5750-W has a 12 ~ 24V DC for automotive use and a legacy RS232/422/485 COM Port selectable by BIOS, making the system very suitable for automation purposes.
4-screen ChromeOS Flex device can endure harsh temperatures
8K HDR content playback
This digital signage media player is capable of driving 8K content. With a resolution that goes up to 7680 x 4320 pixels, your content is displayed clearly.
Intel Core-i Platform
The DEX5750 combines a high-performance CPU, up to 23% faster single thread performance, and up to 19% faster multi-thread performance. With new Intel® Iris® Xe graphics, offers up to 2.95 times faster graphics performance. These computing devices are available with Core - i3, i5 CPU in different SKU's.
-20º operating temperature
AOPEN has good experience in mechanism and electronic design. It has designed a good body temperature control for DEX5750-W. The equipment can operate normally even at a low temperature of minus 20 degrees C. It is suitable for industrial or outdoor applications that require low temperatures.
4-screens output player
DEX5750-W supports 4 screen output solutions, which can support up to 4 screens (via USB-C). The horizontal or vertical streamlined ratio is the best solution for digital menus, video walls and multi-screen use. It is suitable for application industries such as fast catering and fast fashion retail, with special effects such as screen changes.
Fanless design
With fanless design, the device is passively cooling and is dustproof. Therefore, it's very suitable for segments such as industry.
Small form factor
This form factor ensures an easy integration into kiosks or behind screens. The AOPEN small form factor is a standard that is used for Digital Engine (DE) models.
AOPEN Intelligent Control
AOPEN Intelligent Control (AiCU) is built for global enterprise brands, AiCU enables network operators with an intelligent device management solution that automates industrial and commercial applications. AiCU brings cloud service and advanced embedded device control technology together into a single dashboard.
Processor
- CPU Modell
- Intel® Core™ i5-1135G7 Intel 7th Gen Kaby Lake U ≦ 15W
Minne
- Internminne
- 16 GB 8Gx2
- Minnestyp
- DDR4 SO-DIMM
- Max minne
- 64 GB
- Minnesplatser
- 2 st.
Grafikkort
- GPU Modell
- Intel Iris Xe Graphics
- Bildanslutningar
- 4 st.
Lagring
- HDD Typ
- M.2 SSD x 2
- HDD Storlek
- 240 GB
Anslutningar
- HDMI
- Ja x2 (HDMI2.0)
- DisplayPort
- Ja x2 (DisplayPort 1.4)
- USB typ-A
- Ja x6
Kommunikation
- Ethernet
- Ja 100/1000/2500 Mbps
Energi
- Strömförsörjning
- AC 100 ~ 240V, 90W (19V, 4.74A) AC Adapter
Mått och vikt
- Bredd
- 240 mm
- Djup
- 158 mm
- Höjd
- 35 mm
- Nettovikt
- 1,69 kg
Övrigt
- Garanti
- 2 år
Förpackningsinfo
- Förpackningsstorlek
- 322 x 210 x 101 mm
- Förpackningsvikt
- 2,53 kg
