Single output power 20 W

Input voltage range 85 - 264 VAC 47 - 63 Hz

DC output voltage 12 V

DC output current 0 - 1.67 A

Output ripple and noise 120 mVp-p

Line regulation ±1 %

Load regulation ±1 %

Efficiency 80 %

Adjustable range for DC voltage ±1 %

Test standard EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, EN 55022:2010, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010/A1:2015

Inrush current Cold start current 20 A / 115 VAC; 40 A / 230 VAC

Overload protection 105 % - 160 % cut off the output, automatic recovery

Over voltage protection 120 % - 140 % shut down O/P voltage, off / on cycle required for recovery

Setup, rise, hold up time 500 ms, 30 ms / 230 VAC at full load; 1000 ms, 30 ms / 115 VAC at full load

Withstand voltage I/P-O/P: 1.5 kV; I/P-FG: 1.5 kV; O/P-FG: 0.5 kV 1 minute

Isolation resistance I/P-O/P I/P-FG O/P-FG: 500 VDC / 1000 MΩ

Working temperature -10 °C - +50 °C

Mounting options 35 mm DIN Rail

Dimensions 22.5 x 90 x 100 mm

Weight 190 g
