ASUS Prime series is expertly engineered to unleash the full potential of 3rd Generation AMD Ryzen platform. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, Prime B550 series motherboards provide daily users and DIY PC builders a range of performance tuning options via intuitive software and firmware features.
Tune It Your Way
Comprehensive controls form the foundation of the ASUS Prime series. The Prime B550 motherboard packs flexible tools to tune every aspect of your system, enabling you to tweak performance settings to perfectly match the way you work – maximizing your productivity.
Cooler by Design
Prime B550M-K is engineered with an array of hybrid fan headers and features comprehensive cooling controls that are configurable via Fan Xpert 2+ software or via the UEFI BIOS, ensuring your rig stays cool and stable under intense workloads.
Build on a Solid Foundation
Prime B550 motherboard provides all the fundamentals to boost daily productivity, so your system will be ready for action with stable power, intuitive cooling and flexible transfer options.
Little Things Make a Big Difference
Prime B550 series adds the nuanced details that improve every experience, from exclusive codecs that provide pristine audio quality to intuitive interface that let you customize your system to create a uniquely personal look.
Outstanding Audio
Combined onboard features deliver elevated audio
Intelligent design and premium hardware create audio quality unlike anything you've ever experienced.
- DVI
- Ja 1 x DVI-D
Generelt
- CPU-Socket
- AMD AM4
- Chipset
- AMD B550
- Form factor
- micro ATX
Hukommelse
- Memory Type
- DDR4-SDRAM
- Memory frequency (base)
- 2.133 MHz
- Memory frequency (OC)
- 4.600 MHz
- Memory slots
- 4 pcs.
- Max Memory
- 128 GB
Expansion Slots
- PCIe generation
- 4.0
- PCIe x16
- 1 pcs.
- PCIe x1
- 2 pcs.
Lagerenheder
- M.2 slots
- 2 pcs.
- M.2 support
- PCIE 4.0 x4 and SATA modes
- M.2 interface
- Socket 3 with M key
- SATA ports
- 4 pcs.
Kommunikation
- WiFi
- Nej
- LAN controller
- Realtek RTL8111H
- LAN hastighed
- 1 Gb/s
Internal I/O Connectors
- TPM
- Ja
- RGB
- Nej
- Fan Connector (4-pin)
- 3 pcs.
Rear Panel Ports
- USB type-A
- Ja 2 x USB 3.2 Gen 2, 4 x USB 3.2 Gen 1
- HDMI
- Ja 1x
- VGA
- Ja 1x
- AUX ud
- Ja 3 x Audio jack(s)
- Ethernet
- Ja 1 x LAN (RJ45) port
- PS/2
- Ja 1 x PS/2 keyboard/mouse combo port(s)
Dimensioner og vægt
- Bredde
- 244 mm
- Længde
- 244 mm
Forpakningsinfo
- Forpaknings størrelse
- 270 x 260 x 51 mm
- Forpaknings vægt
- 898 g
Forpakningsinfo (10 pcs)
- Forpaknings størrelse
- 450 x 450 x 500 mm
- Forpaknings vægt
- 9,00 kg
