Key Features
AMD Socket AM5：Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
Digital twin 16+2+2 phases VRM solution
Dual Channel DDR5：4DIMMs with AMD EXPO™Memory Module Support
WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation
EZ-Latch Plus：PCIe and M.2 slots with Quick Release & Screwless Design
EZ-Latch Click：M.2 heatsinks with screwless design
Sensor Panel Link：Onboard video port for hassle-free in-chassis panel setup
Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
Ultra-Fast Storage：4M.2 slots, including 3* PCIe 5.0 x4
Efficient Thermal：VRM Thermal Armor Advanced & M.2 Thermal Guard L
Fast Networking：2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
Extended Connectivity：Dual USB4 Type-C with DP-Alt, HDMI
Reliable Audio：Realtek ALC1220 HD Audio & Audiophile Grade Capacitors
Ultra Durable PCIe Armor : The metal back plate of PCIe x16 slot for enhanced durability
PCIe UD Slot X：PCIe 5.0 x16 slot with 10X strength for graphics card
Generelt
- CPU-Socket
- AMD AM5
- Chipset
- X870
- Form factor
- ATX
Hukommelse
- Memory Type
- DDR5
- Kanal understøttet
- Dual Channel
- Memory frequency (base)
- 4.400 MHz
- Memory frequency (OC)
- 8.000 MHz
- Memory slots
- 4 pcs.
- Max Memory
- 256 GB
Expansion Slots
- PCIe x16
- 1 pcs.
- PCIe x1
- 1 pcs.
- PCIe x4
- 1 pcs.
Lagerenheder
- M.2 slots
- 4 pcs.
- SATA ports
- 4 pcs.
Kommunikation
- Wi-Fi
- Ja
- WiFi Standard
- MediaTek Wi-Fi 7 MT7925
- Bluetooth
- Ja
- Bluetooth standard
- BLUETOOTH 5.4
Internal I/O Connectors
- TPM
- Ja
- RGB
- Ja
Rear Panel Ports
- USB type-A
- Ja
- USB type-C
- Ja
- HDMI
- Ja
- DisplayPort
- Ja USB4® USB Type-C® port
Dimensioner og vægt
- Bredde
- 305 mm
- Længde
- 244 mm
Forpakningsinfo
- Forpaknings størrelse
- 280 x 340 x 88 mm
- Forpaknings vægt
- 2,25 kg
Forpakningsinfo (5 pcs)
- Forpaknings størrelse
- 420 x 280 x 320 mm
- Forpaknings vægt
- 13,00 kg
