Intuitive professional content delivery
Great first impressions can make all the difference; presenting your business in the best possible way will boost your brand. With slim, modern styling, 24/7 operation and high haze panel to reduce reflections when ambient light is high, the Mxx1-2 series is the professional way to deliver your message, yet at an attractive price point.
With the optional Raspberry PI Compute Module or the more powerful Intel® Smart Display Module (Intel® SDM) computing device, you are primed and ready for intuitive signage creation delivering real-time media playback for exceptional visual experiences. For advertising, infotainment and meeting room applications, the Mxx1-2-2 Series provides powerful, upgradable functionality and all the aesthetic appeal to effortlessly reflect your brand credentials.
- Modern and slim design – robust yet elegant allowing for an unobtrusive integration into any application and environment.
- Secure remote management – control your devices remotely and securely using NEC NaviSet Administrator 2; proactively manage maintenance requirements saving time and resources
- Ease of use and operation – smart installation, operation and maintenance functionality ensures accurate performance over the entire lifetime of the display saving time, effort and resources.
- Future Ready Connectivity – featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.
- Effortless content playback – the integrated USB media player supports various image video file formats for effortless and standalone content playback.
Special features:
DICOM Simulation; HDMI ARC; Powered USB Port (10 W); Removable Logo
External Control
AMX NetLinx Support; ASCII Control Commands; Crestron Connected; HDMI CEC; HTTP Browser; PJLink; Scheduled Timer; SNMP
Remote Management
Automated Email Alerts; NEC NaViSet Administrator 2
Security
Disable HW Buttons; Disable IR Functionality; Emergency Notification
Display
- Drifttid
- 24/7
- Billed diagonal
- 65 "
- Opløsning
- 3840x2160
- Brightness
- 500 Nits
- Haze value (%)
- 25
- Portræt
- Ja
Functions
- Beskyttelsesglas
- Nej
- Videovæg
- Nej
- Udendørs brug
- Nej
- TV Tuner
- Nej
- Indbygget speaker
- Ja 2x10W
- Mediaplayer
- CM-Slot (Raspberry Pi) RPi Compute Module 4
- Mediaplayer
- SDM-Slot Accepts Intel® Smart Display Modules Large and Small up to 66 W; compatible with Intel Celeron CPUs or CPUs with lower power consumption
- Mediaplayer
- USB mediaplayer Simple USB mediaplayer for images, video and music files.
Connections
- Video ind
- DisplayPort x1
- Video ind
- HDMI x2
- Audio Udgange
- 3,5mm tele
Communication
- Ethernet
- Ja 100Mbit
- Wi-Fi
- No
- Trådløs billeddeling
- Nej
Energy
- Strømforsyning
- 100-240 V AC; 50/60 Hz; internal Pos
- Forbrug Stand-by
- 0,5 W
- Forbrug Typisk
- 165 W
Dimensions and weight
- VESA mount interface (mm)
- 400x400 M8
- Bredde
- 1.462,3 mm
- Højde
- 837,3 mm
- Dybde
- 68,1 mm
- Nettovægt
- 29,4 kg
Yderligere oplysninger
- Inkluderet tilbehør
- 2x AAA batteries; Display; HDMI Cable; Power Cable; Remote Control; Setup Manual
- Garanti
- 3 år incl. backlight; additional services available. Optional 4. + 5. year warranty extension
Forpakningsinfo
- Forpaknings størrelse
- 1.736 x 1.033 x 280 mm
- Forpaknings vægt
- 62,00 kg
